Suitable for batteries，solar energy and other equipment requiring automatic charging(UPS)
Input reverse connection protection by fuse
Design efficiency 90%
2 years guarantee
| Model |
KYNB-C3000 -212 |
KYNB-C3000 -224 |
KYNB-C3000 -248 |
KYNB-C3000 -260 |
KYNB-C3000 -112 |
KYNB-C3000 -124 |
KYNB-C3000 -148 |
KYNB-C3000 -160 |
|
Input Volt (V dc） |
12 | 24 | 48 | 60V | 12 | 24 | 48 | 60V |
|
Input Volt (V dc） |
10.5-15.5 | 21-30VDC | 42-62VDC | 50-75VDC | 10.5-15.5 | 21-30VDC | 42-62VDC | 50-75VDC |
|
Output Volt （V ac） |
220/230/240AC ±3%a |
100/110/120 ±3%a |
||||||
|
Rated Power （W) |
3000 | |||||||
|
Surge Power （W） |
6000 | |||||||
|
Low Volt Alarm |
10VDC±0.5 | 20.5VDC±-1V | 44VDC±1V | 55VDC±1V | 10VDC±0.5V | 20.5VDC±1V | 44VDC±1V | 55VDC±1V |
|
Low Volt Shut Down |
9.5VDC±0.5V | 19.5VDC±0.5V | 42VDC±1V | 52VDC±1V | 9.5VDC±0.5V | 19.5VDC±0.5V | 42VDC±1V | 52VDC±1V |
|
Effciency (%) |
0.92 | 0.93 | 0.94 | 0.94 | 0.92 | 0.93 | 0.94 | 0.94 |
